Home 2002 Chrysler 300M Base 3.5L V6 - Gas Differential

Differential for 2002 Chrysler 300M

Differential for 2002 Chrysler 300M #0

1

10

11

11

12

15

15

17

19

2

20

21

23

26

26

27

27

28

3

4

5

6

7

8

8

9

No.

Part # / Description / Price

Price

N/A

6502482 - Automatic Transaxle 4 Speed: Snap Ring for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Snap Ring

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

Description: Stub Shaft Ball Bearing, 2.634`` O.D., .078`` Thk. Stub with Ball Bering.

1

4539661 - Automatic Transaxle 4 Speed: Transaxle Differential for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Trans-Axle Differential

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

2

4593012 - Automatic Transaxle 4 Speed: Half Shaft Circlip for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Half Shaft Circlip

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

3

4539748 - Automatic Transaxle 4 Speed: Transaxle Output Shaft for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Trans-Axle Output Shaft

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

4

2852883 - Automatic Transaxle 4 Speed: Drive Shaft Lock for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Drive Shaft Lock

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

5

6502034 - Automatic Transaxle 4 Speed: Special Shouldered Screw for Chrysler: 200, 300M, Concorde, Pacifica, PT Cruiser, Sebring, Town & Country, Voyager | Dodge: Avenger, Caliber, Caravan, Grand Caravan, Intrepid, Journey, Neon, Stratus | Jeep: Compass, Patriot | Ram: C/V, ProMaster 1500, ProMaster 2500, ProMaster 3500 Image

Special Shouldered Screw

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

Description: M10x1x29. Fwd.

MSRP $6.75

$6.00

MSRP $6.75

$6.00

6

4567505 - Automatic Transaxle 4 Speed: Transfer Front Case for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Transfer Front Case

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

7

4567225 - Automatic Transaxle 4 Speed: Support Case Bushing for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Support Case Bushing

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

8

4131293 - Automatic Transaxle 4 Speed: Axle Differentail Thrust Washer Package for Chrysler: 200, 300M, Concorde, Pacifica, Sebring, Town & Country | Dodge: Avenger, Grand Caravan, Intrepid, Journey | Ram: C/V, ProMaster 1500, ProMaster 2500, ProMaster 3500 Image

Differential Thrust Washer Package

Mopar

Mopar

Notes: Engines: 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

Description: THRUST

MSRP $87.00

$57.46

MSRP $87.00

$57.46

9

5016367AA - Automatic Transaxle 4 Speed: Differential Gear Package for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Differential Gear Package

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

10

154567 - Automatic Transaxle 4 Speed: Shift Fork Pin for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Shift Fork Pin

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

11

2852912 - Automatic Transaxle 4 Speed: Pinion Thrust Washer for Chrysler: 300M, Aspen, Concorde | Dodge: Dakota, Durango, Intrepid, Nitro, Ram 1500 | Jeep: Cherokee, Commander, Grand Cherokee, Liberty | Ram: 1500, Dakota Image

Pinion Gear Thrust Washer

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

Description: Also Serviced In Item 56. Also Service in Differential Gear Package.

12

6501714 - Automatic Transaxle 4 Speed: Hex Head Screw And Washer for Chrysler: 300M, Concorde, PT Cruiser, Sebring, Town & Country, Voyager | Dodge: Caravan, Dakota, Durango, Grand Caravan, Intrepid, Neon, Ram 2500, Ram 3500, Stratus | Jeep: Commander, Liberty | Ram: Dakota Image

Hex Head Screw And Washer

Mopar

Mopar

Description: M6x1x18. Camshaft Sensor mounting. Canshaft sensor attaching. M6x1.001x18.00. Vehicle speed sensor. To Manifold. Balance Shaft Cover. Oil Level Indicator Tube To Engine Block.

15

4567617 - Automatic Transaxle 4 Speed: Differential Ring Gear for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Differential Ring Gear

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

17

6502363 - Automatic Transaxle 4 Speed: Cv Joint O Ring for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Cv Joint O Ring

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

19

4539879 - Automatic Transaxle 4 Speed: Differential Bearing for Chrysler: 300M, Concorde | Dodge: Intrepid | Jeep: Grand Cherokee Image

Trans-Axle Output Shaft

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

Description: Sealed Ball, 2-3/8`` O.D., 5/8`` Width. Stub with Ball Bering.

20

4567216 - Automatic Transaxle 4 Speed: Transaxle Output Shaft for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Trans-Axle Output Shaft

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

Description: Stub with Ball Bering.

20

4539759 - Automatic Transaxle 4 Speed: Transaxle Output Shaft for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Trans-Axle Output Shaft

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

Description: Stub with Ball Bering.

21

4412235AB - Automatic Transaxle 4 Speed: Output Shaft Bearing Cone for Chrysler: 200, 300, 300M, Concorde, Pacifica, PT Cruiser, Sebring, Town & Country, Voyager | Dodge: Avenger, Caravan, Challenger, Charger, Dakota, Durango, Grand Caravan, Intrepid, Journey, Magnum, Neon, Nitro, Ram 1500, Stratus | Jeep: Liberty, Wrangler | Ram: 1500, Dakota Image

Output Shaft Bearing Cone

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

Description: Fwd.

MSRP $129.00

$83.81

MSRP $129.00

$83.81

23

1790541 - Automatic Transaxle 4 Speed: Differential Bearing for Chrysler: 200, 300M, Aspen, Concorde, Pacifica, Sebring, Town & Country | Dodge: Avenger, Dakota, Durango, Grand Caravan, Intrepid, Journey, Nitro | Jeep: Cherokee, Commander, Grand Cherokee, Liberty | Ram: C/V, Dakota, ProMaster 1500, ProMaster 2500, ProMaster 3500 Image

OEM NEW Mopar 2012 - 2018 Dodge Ram Jeep Chrysler Differential Bearing 1790541

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

Description: Case Cone. Side Cone.

MSRP $145.00

$94.86

MSRP $145.00

$94.86

26

4593110 - Automatic Transaxle 4 Speed: Differential Side Gear for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Differential Side Gear

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

27

4593112 - Automatic Transaxle 4 Speed: Differential Pinion for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Differential Pinion

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

28

2852913 - Automatic Transaxle 4 Speed: Differential Pinion Shaft for Chrysler: 300M, Concorde | Dodge: Intrepid Image

Differential Pinion Shaft

Mopar

Mopar

Notes: Engines: 2.7L V6 24V W/ACTIVE INTAKE ENGINE. 2.7L V6 DOHC 24 VALVE MPI ENGINE. 3.2L V6 SOHC 24 VALVE MPI ENGINE. 3.5L V6 HIGH OUTPUT 24V MPI ENGINE. 3.5L V6 SOHC 24 VALVE ENGINE. 3.5L V6 SOHC 24V ENGINE. Transmissions: 4-SPEED AUTOMATIC TRANSMISSION.

}); });
